16kWh ESS
SAFE: Grade A LiFePO₄ Cell
RELIABLE: Compatible with Major PCS Brand
SCALABLE: Scalable From 14.3 To 1008 kWh
Product Description
Discover how our comprehensive solutions empower your journey.
Nominal Voltage:51.2 Vdc
Nominal Capacity:314 Ah
Charge Power:7.68kW
Cell Technology: LiFePO₄ ,Lithium Iron Phosphate
DischargePower:10.24kW
Short Circuit Current:540A
Display:Color touchscreen
Weight (kg):120kg
Operating Temperature:Charge: 0~55°C / Discharge: -20°C ~ 55°C
Operating / Storage Humidity:≤95% RH
Max Operating Altitude:≤2000m
Battery Energy:16 kWh
Charge Current:150 A
Discharge Current:200A
IP Rating:IP20
Communication:CAN, RS485, RS232
Dimension (WxDxH mm):450x 230x 800 mm
Installation:Floor Stand
Scalability:Max 63 batteries in parallel
Cycle Life:8000 Cycles @ 80% DoD /25°C/0.5C, 60% EOL
Certificates:IEC 62619, IEC 61000, IEC 62040, UN38.3
Product Ordering Part:SUN-16K Battery(Cable included)
