Modular Stackable ESS
Model: lite 5220-3U
Product Description
Discover how our comprehensive solutions empower your journey.
Nominal Voltage:51.2 Vdc
Nominal Capacity:102 Ah
Charge Power:2.56kW
Cell Technology: LiFePO₄ ,Lithium Iron Phosphate
DischargePower:5.12 kW
Short Circuit Current:350A
Display:SOC status indicator, LED indicator
Weight (kg):43 kg
Operating Temperature:Charge:
0~55°C/Discharge: -20°C ~ 55°C
Operating / Storage Humidity:≤95% RH
Max Operating Altitude:≤2000m
Battery Energy:5.2 kWh
Charge Current:50A
Discharge Current:100A
IP Rating:IP20
Communication:CAN, RS485, RS232
Dimension (WxDxH mm):440x 500 x 132mm
Installation:Rack Mounted
Scalability:Max 15 batteries in parallel
Cycle Life:6000 Cycles @ 80% DoD /25°C/0.5C, 60% EOL
Certificates:CE, UN38.3
Product Ordering Part:ite 4900-3U / lite 5220-3U (Mini Rack Included)10x 3U Rack25 mm’ Power Cable Set
