Energy Storage Lithium Battery
Model: LAR 2940-12.8V
Nominal Ratings: 12.8 Vdc, 230 Ah, 2,94 kWh
Product Description
The 2.94kWh IP65 Energy Storage Lithium Battery is an energy-storage solution for home emergency backup and outdoor portable power. Built with Grade-A LiFePO₄ cells, it features mainstream hardware interfaces for everyday devices and delivers up to 8000 cycles. Replacement warranty options ranging from 5 to 10 years are available upon request.
Nominal Capacity: 102 Ah
Nominal Voltage: 12.8 Vdc
Bulk Charge V: 14 Vdc
Float Charge Voltage: 13.8 Vdc
Battery Energy: 2.94kWh
IP Rating: IP65
Operating Temperature: (charge )0 ~ 55°C / (discharge) -20°C ~ 55°C
Operating Humidity: ≤95% RH
Max Operating Altitude: ≤2000m
Weight (kg):19.6kg
Dimension: 502 x 186 x 241 mm
Installation: floor stand
Cell Technology: LiFePO4
STD Charge Current: 100A
Max Continuous Discharge: 200A
Cutoff Voltage: 11.6 Vdc
Cycle Life: 8000 Cycles @ 80% DoD / 25°C / 0.5C, 60% EOL
Certificates: IEC 62619, IEC 61000, IEC 62040, UN38.3, CE
Product Ordering Part: LAR 2940-12.8V
Scalability: Max 2 batteries in series | 4 batteries in parallel
BMS: included
Compatibility: interfaces for mainstream devices
